JRF-PM460 is based on the high thermal conductivity of silica, boron nitride and aluminum oxide powder mixed into, the product can meet the requirements of heat radiating occasions for high and stable insulation performance. The product has good thermal conductivity, at the same time, this product has the self adhesive ,application and operation is simple and convenient.
JRF-PM460 is use of soft silicone material thermal conductive, good insulation performance, soft and elastic characteristics, placed between the power heating device and heat dissipating structure, the power module generates heat effectively transmit to the radiating component.
1. Car engine module and vehicle electronic equipment
2. Notebook computer, table computer CPU
3. Flat panel TV, mobile equipment, high-speed hard disk driver
4. Semiconductor and the radiating fin between
5. Computer, PC server, workstation
6. LED lighting device and mass storage device
Performance and characteristics:
1.High thermal conductivity, heat transfer coefficient 4.6W/m-k
2.Stable performance , low thermal resistance, effectively improve the heat transfer speed
3.Low hardness , its viscosity high, easy to use adhesive
4.By UL and V-O certification standards
Standard size 310mm*310mm, 200mm*400mm according to customer needs cutting type
Basic thickness 0.25mm*5.0mm, special size and thickness can be customized
Itself is slightly viscous, if need to strengthen the adhesive can be according to customer’ requirement.
Product color is mass production, if need special color can be adjusted according to the actual situation
